Scientific Optical Hardware Diagram

原文

GPT Image 2 · en

{
  "type": "Scientific hardware schematic diagram",
  "layout": {
    "main_scene": "A 3D rendering of the optical platform, showing a red laser beam passing through 11 aligned optical components mounted on a black pillar.",
    "top_brackets": [
      {
        "label": "Dual modulation",
        "span": "SLM1"
      },
      {
        "label": "4f relay optical system",
        "span": "Lens L1 to Lens L2"
      },
      {
        "label": "Imaging Optical System",
        "span": "SLM2 to Lens L4"
      },
      {
        "label": "Detection",
        "span": "camera"
      }
    ],
    "optical_components_left_to_right": [
      {
        "name": "laser",
        "labels": [
          "laser",
          "λ = {argument name=\"laser wavelength\" default=\"632.8 nm\"}"
        ]
      },
      {
        "name": "SLM1",
        "labels": [
          "SLM1",
          "(Phase/Polarization Modulation)"
        ]
      },
      {
        "name": "Lens L1",
        "labels": [
          "Lens L1",
          "(f1)"
        ]
      },
      {
        "name": "Aperture",
        "labels": [
          "Fourier plane",
          "(Pupillary plane)",
          "Aperture",
          "(Filter out higher-order terms)"
        ]
      },
      {
        "name": "Half-wave plate (HWP)",
        "labels": [
          "HWP",
          "(λ/2)"
        ]
      },
      {
        "name": "Lens L2",
        "labels": [
          "Lens L2",
          "(f1)"
        ]
      },
      {
        "name": "SLM2",
        "labels": [
          "SLM2",
          "(Phase/Polarization Modulation)"
        ]
      },
      {
        "name": "Lens L3",
        "labels": [
          "Lens L3",
          "(f2)"
        ]
      },
      {
        "name": "Lens L4",
        "labels": [
          "Lens L4",
          "(f2)"
        ]
      },
      {
        "name": "Linear polarizer",
        "labels": [
          "linear",
          "-Polarizer",
          "(Global Analyzer)"
        ]
      },
      {
        "name": "polarization camera",
        "labels": [
          "polarization camera"
        ]
      }
    ],
    "inset_box": {
      "position": "bottom right corner",
      "title": "Polarization camera micro-polarizer array (pixel-level analyzer)",
      "grid": "4x4 Colored Square Grid with Directional Arrows",
      "legend_count": 4,
      "legend_items": [
        "Red square, horizontal arrow, 0° (H)",
        "Green square, vertical arrow, 90° (V)",
        "Blue square, diagonal arrow, 45° (D)",
        "Yellow square, diagonal arrow, 135° (A)"
      ]
    },
    "bottom_caption": {
      "figure_prefix": "{argument name=\"figure number\" default=\"Figure 5.\"}",
      "title": "{argument name=\"system name\" default=\"Elliptic polarization imaging hardware settings.\"}",
      "text": "Scientific paragraphs explaining dual modulation configurations, 4f relay optics systems, and polarization cameras."
    }
  }
}

使い方

1. パラメータを含む元のプロンプト全体をコピーします。
2. 被写体、文字、構図を自分の要件に置き換えます。
3. 対応する外部ツールで使用し、利用条件と結果を確認します。

開始前の確認

• 参考画像の要否を確認してください。互換モデルの表示は、そのモデルでの生成実績を意味しません。
• 名前、数値、画像内の文字を確認します。モデルの版で結果は変わります。
